• New composite base pan - dampens sound, captures louver panels, eliminates corrosion and reduces number of fasteners needed
• Powder coat paint system - for a long lasting professional finish
• Scroll compressor - uses 70% fewer moving parts for higher efficiency and increased reliability
• Modern cabinet aesthetics - increased curb appeal with visually appealing design
• Curved louver panels - provide ultimate coil protection, enhance cabinet strength, and increased cabinet rigidity
• Optimized fan orifice - optimizes airflow and reduces unit sound
• Rust resistant screws - confirmed through 1500-hour salt spray testing
• PlusOne™ Expanded Valve Space - 3"-4"-5" service valve space - provides a minimum working area of 27-square inches for easier access
• PlusOne™ Triple Service Access - 15" wide, industry leading corner service access - makes repairs easier and faster. The two fastener removable corner allows optimal access to internal unit components. Individual louver panels come out once fastener is removed, for faster coil cleaning and easier cabinet reassembly
• Diagnostic service window with two-fastener opening - provides access to the high and low pressure.
• External gauge port access - allows easy connection of "low-loss" gauge ports
• Single-row condenser coil - makes unit lighter and allows thorough coil cleaning to maintain "out of the box" performance
• 35% fewer cabinet fasteners and fastener-free base - allow for faster access to internal components and hassle-free panel removal
• Service trays - hold fasteners or caps during service calls
• QR code - provides technical information on demand for faster service calls
• Fan motor harness with extra long wires allows unit top to be removed without disconnecting fan wire

• Conditional Parts (Registration Required): Ten (10) Years
• Rheem will furnish a replacement for any part of this product which fails in normal use and service within the applicable period stated, in accordance with the terms of the limited warranty

• 80% residential Gas Furnace CSA certified
• 3 way multi poise design Upflow/Horizontal
• PlusOne™ Diagnostics - 7 Segment LED all units
• PlusOne™ Ignition System - DSI for reliability and longevity
• Heat exchanger is removable for improved serviceability. Aluminized steel construction provides maximum corrosion resistance and thermal fatigue reliability.
• Solid doors provide quiet operation
• Solid bottom
• Insulated blower compartment
• Low profile 34" cabinet ideal for space constrained installations
• Blower shelf design - serviceable in all furnace orientations
• Integrated Controls board features dip switches for easy system set up
• QR codes for quick access to product information from your smart phone or tablet
• Constant Torque electrically commutated motor

• Rheem® Indoor Furnace cased coils and replacement uncased coils are designed for use with Rheem outdoor units and are available for vertical upflow or downflow, and horizontal left or horizontal right airflow. When matched with Rheem outdoor units, the coils provide a nominal capacity range from 18,000 BTU/HR [5.24 kW] to 60,000 BTU/HR [17.6 kW].
• Constructed of aluminum fins bonded to internally grooved aluminum tubing.
• Coils are tested at the factory with an extensive refrigerant leak check.
• Coils have copper sweat refrigerant connections.
• Feature two sets of 3/4" [14.1 mm] N.P.T. Condensate drain connections for ease of connection.
• Chatleff metering device connections, at inlet and outlet of TXV and equalizer connections.
• Approved for system application with variety of Rheem outdoor units.
• Condensate drain pan is constructed of high grade, heat resistant, corrosion free thermal-set material.
• Compatible with Germicidal Light System (UV resistant)
• Bi-Directional airflow eliminates the need to switch any internal components from horizontal left to right.
• Unique drain pan design maximizes application flexibility and condensate removal.
• N-Coil design maximizes performance and minimizes height required at installation.
• Coils are AHRI certified for system application with a variety of Rheem outdoor units.

The Rheem Story

Rheem Manufacturing Company was established in the mid-1920s when brothers Richard and Donald Rheem acquired a galvanizing plant in San Francisco, California. In the 1930's, Rheem began manufacturing water heaters, and by 1936 had coast to coast distribution. During the 1940s and 1950s, the company increased its product line to include space heating units for homes, oil furnaces and air conditioners.

In 1959, Rheem acquired Ruud Manufacturing Company, a pioneer in the water heating industry with a well-regarded product line and a distribution network throughout North America. In subsequent years, Rheem entered the heating and air conditioning market and expanded in the late 1960's and 1970's with the rapid growth of the central air conditioning industry. In 1985, the company acquired Raypak, a leading producer of copper tube boilers used for swimming pool heating and commercial hot water supply and hydronic heating.

EXAMPLE WARRANTY INFORMATION:

SHIPPING DETAILS

Mostly All Of Our Products Are Shipped Same Or Next Day

Your product will be mostly shipped using Freight Company such as SAIA, ESTES, Old Dominion, FEDEX or UPS and will be delivered in 1-5 business days depending upon your geographical location from our warehouses. We ship products from warehouses in NY, NJ, FL, CA,AZ, TX And MO. Mostly if you are close to our warehouses, you should receive the Product in 1-3 business days. We will email you your tracking number soon as its shipped out or you can log into your account on our website by using your email address and password you created at the time of placing order to check all the shipment and product details.
Please remember we only ship to 48 states within United States. Due to expensive shipment fee we do not ship to Hawaii & Alaska. We do not ship to Canada, Puerto Rico, Jamaica and other countries due to custom issues.

Though above shipment and delivery process is what we normally practice, under unforseen circumstances they cannot be guaranteed at all times. But we do our best and mostly succeed to ship the product either same or the next day.

Overnight Shipping Details (if required)

We can ship overnight or by Second Day Air. But beacuse these are air conditioners and the package weighs more than 90 pounds usually, shipping overnight can result in the package being mishandled and delivered damaged. Plus it cost anywhere from $180-$850 more than regular shipping depending upon your location from our warehouse. Feel free to email us with such enquiries.
